KB & KM Series Peristaltic Metering Pumps
The Albin Pump portfolio has expanded to include the KB and KM Series cased-drive tubing pumps. KB is a versatile and economical peristaltic metering pump for high-precision dosing in water treatment or wastewater treatment applications.
These revolutionary new pumps offer:
Next-generation safety features:
A patent-pending offset rotor assembly releases tube compression during maintenance
Tube changes do not require users to manipulate the tube while rotor is turning
Offset rotor allows drain and flush of tube prior to removal
A best-in-class user experience featuring one-button switching between local and remote operation
No need for complex, multi-step menu navigation each time a mode change is required
Basic pumps with local control, with an optional upgrade to include remote control protocols
KM Series pumps feature 10,000:1 turndown, NSF-61 certification, and a 5-year warranty
FEATURES:
4.33” color LCD display
Optical tube leak detection standard
Remote inputs available: 4-20mA, SCADA, Modbus
Onboard run timer for predictive maintenance
Equipped with USB port for firmware upgrades
ADVANTAGES:
Each rotation gives the same displacement, which provides excellent chemical metering ability
Suction lift up to 30 feet (9 meters)
No backflow or slip allowed
Self-priming peristaltic metering pump delivers smooth chemical feed
No moving parts in liquid path – tubing is the only wetted item
No check balls or check valves
No damage from running dry
Pump will not vapor lock or air bind
SPECIFICATIONS:
